Fast Wrapping SWT25120M Automatic Cable Tie Tool For Vacuum Cleaner Motor Tie Wrapping Fast
SWT25120M is a special automatic cable tie tool machine. Its fixed cable tie gun is different with other handheld cable tie gun. It can bundle some objects with only small space that cable ties go through. It is faster than by hand.
Technical data
| Name | Automatic cable tie tool |
| Model | SWT25120M |
| Cable ties material | nylon 66 |
| Bundle items' dia. | 11mm - 15mm |
| Using cable ties | W2.5 * L120mm |
| Bundle speed | 1.0S |
| Bundle forces | Adjustable |
| Voltage | AC220V, 50/60Hz |
Remark,
1.If your products are special, such as motor coils or others, you could choose the automatic cable tie gun SWT25120M.
If the products are wire harness, please choose handheld cable tie gun, SWT25100H or SWT25120H.
2.SWT25120M only deals with nylon cable ties T25120.
3.The max bundle diameter for products is 15mm when you use this machine.
Features
1. The cable tie gun is fixed to bundle items with nylon cable ties.
2. Using loose nylon cable ties. The size is W2.5 * L120mm, Model T25120
3. Help you to save time and improve the productivity.
4. The bundle speed is 1.0S and is faster than by hand.
5. Tread the foot pedal, it would start to wrap, pull and tighten, cut off cable ties.
6. The bundle diameters: 11mm - 15mm.
7. Cable tie gun weight is 6kg.
Packing details
Be packed in two wooden cases
Applications
Be more suitable for bundling objects which has small room for cable tie to go through.
| 1. Motor coils for vacuum cleaners, washing motors etc. |
| 2. Smaller outer winding stators. |
| 3. Other objects with small room. |
Related auto tie wrap machine
1. Automatic cable tie tool – Handheld type.
| Model | Using nylon cable ties | Binding diameters for products | Operate speed |
| SWT25080H | T25080 | 2mm – 14mm | 0.7S |
| SWT25100H | T25100 | 2mm – 18mm | 0.7S |
| SWT25120H | T25120 | 2mm – 22mm | 0.8S |
| SWT36100H | T36100 | 3mm – 18mm | 0.8S |
| SWT36120H | T36120 | 3mm – 22mm | 0.9S |
| SWT36150H | T36150 | 3mm – 31mm | 1.0S |
2. Automatic cable tie tool – Fixed type.
3. Automatic cable tie machine – Desktop type.
4.Automatic cable tie gun – Robot arm.
FAQ
1. Could I adjust the force?
Yes, you can. There are 4 binding forces to choose. Please turn a knob.
2. Could I use our own cable ties in the machine?
Yes, you can but at first, we have to confirm the cable ties quality. If they are good, we could customize one for you.
3. How about the delivery time?
About 12 -15days after receive the payment.
In Shanghai
